Electric Control Valve with Resetter, SS, 1-1/2 Inch, 150 LB

Electric Control Valve with Resetter, SS, 1-1/2 Inch, 150 LB
Electric Control Valve with Resetter, SS, 1-1/2 Inch, 150 LB
Introducing the Explosion-proof Control Valve with Resetter: equipped with an Electric Multi-turn Actuator, 1-1/2 Inch size, Class 150 LB rating, crafted from Stainless Steel, DN40 size, PN16 pressure rating, and featuring a Flanged Connection.

Detail Information

Electric Multi-turn Explosion-proof Actuator

Product Name: Explosion-proof Control Valve with Resetter
Material: Stainless Steel
Nominal Size: 1-1/2 Inch Inch, DN40
Pressure Rating: Class 150 LB, PN16
Connection Type: Flanged
Seat Material: EPDM/PTFE
Working Temperature: EPDM: -45°C - 80°C / PTFE: -30°C - 180°C
Operation: Electric
Applications: Water, solvent, acid, natural gas, oxygen, hydrogen peroxide, methane, ethylene, etc.


Advantages of Products

Construction: Features a simpler, lighter, and more compact design, making it ideal for applications where space and weight are critical.

Medium Handling: Efficiently conveys muck and minimizes liquid accumulation at the pipeline's mouth, ensuring smooth flow and preventing blockages.

Easy Maintenance: Equipped with a 2-section valve stem without pins, making it straightforward to maintain and disassemble, thus reducing downtime.

Reliable Sealing: Utilizes PTFE as the sealing material, which is resistant to corrosion and aging, ensuring long-lasting and effective sealing performance.

Versatile Actuator Options: Available with on-off, adjustable, and intelligent actuator types, providing flexibility to suit various operational needs.

Quick Response: Offers rapid opening and closing capabilities, enhancing operational efficiency and responsiveness.

Temperature Resistance:

PDEM: Suitable for temperatures ranging from -10°C to 120°C.

PTFE: Effective in a wider range, from -30°C to 180°C.
