Top Guided Angle Control Valves, Chrome-moly Steel, 2-1/2 IN
Key Specifications / Features
As a leading manufacturer of top-guided angle control valves, we offer precision-engineered valves designed for high-pressure applications. Our valves are made from robust chrome-moly steel and are available in a 2-1/2 inch size with a pressure class of 2500 LB. They are also compatible with DN65 and PN420 standards. Depending on your operational needs, our valves can be equipped with diaphragm, piston, or electric actuators to ensure precise control and reliable performance.
- Hits: 23
- Categories: Other Control Valves
- Tags: Top-Cuide Control Valve, Chrome Molly Control Valve, 2-1/2 Inch Control Valve
Detail Information
Design Code: ASME B16.34
Valve Size: 2-1/2 Inch, DN65
Pressure: Class 2500 LB, PN420
End Connection: Flanged, Hubbed, Butt weld
Body Material: Carbon steel, Chrome-moly steel, Stainless steel, Monel, Alloy 20, Hastelloy B/C, Duplex stainless steel, Aluminium bronze
Bonnet: Standard up to 400°C Normalising between 250°C to 500°C Extended cold service -20°C to -100°C
Cryogenic: -100°C to -250°C Bellowseal
Gland Packing: PTFE Chevrons, Graphite, Low emission
Trim Form: Top guided contoured, Spline Micro Flow Ported cage (unbalanced / balanced) Low Noise (LR1, LR2, LR3, LR4)
Trim Material: Stainless steel, Duplex stainless steel, 13% Chrome steel, Monel Hastelloy B/C, Stellite
Flow Characteristic: Equal Percentage, Linear, Quick Opening
Seat Leakage: As per ANSI / FCI 70-2-2006 Class III, IV, V and VI
Actuator Form: Diaphragm, Piston or Electric
Actuator Type: Direct / Reverse Acting
Diaphragm: Nitrile / Neoprene (nylon reinforced)
Accessories: Valve Positioners - Pneumatic, Electro-Pneumatic, Smart
Instruments: Airset, Solenoid Valve, Volume Booster, Airlock, Limit Switches
Features: Top or Side Mounted hand wheel, Limit Stops Removable Blind Head, Steam Jacketing etc.
Valve Size: 2-1/2 Inch, DN65
Pressure: Class 2500 LB, PN420
End Connection: Flanged, Hubbed, Butt weld
Body Material: Carbon steel, Chrome-moly steel, Stainless steel, Monel, Alloy 20, Hastelloy B/C, Duplex stainless steel, Aluminium bronze
Bonnet: Standard up to 400°C Normalising between 250°C to 500°C Extended cold service -20°C to -100°C
Cryogenic: -100°C to -250°C Bellowseal
Gland Packing: PTFE Chevrons, Graphite, Low emission
Trim Form: Top guided contoured, Spline Micro Flow Ported cage (unbalanced / balanced) Low Noise (LR1, LR2, LR3, LR4)
Trim Material: Stainless steel, Duplex stainless steel, 13% Chrome steel, Monel Hastelloy B/C, Stellite
Flow Characteristic: Equal Percentage, Linear, Quick Opening
Seat Leakage: As per ANSI / FCI 70-2-2006 Class III, IV, V and VI
Actuator Form: Diaphragm, Piston or Electric
Actuator Type: Direct / Reverse Acting
Diaphragm: Nitrile / Neoprene (nylon reinforced)
Accessories: Valve Positioners - Pneumatic, Electro-Pneumatic, Smart
Instruments: Airset, Solenoid Valve, Volume Booster, Airlock, Limit Switches
Features: Top or Side Mounted hand wheel, Limit Stops Removable Blind Head, Steam Jacketing etc.
