The main function of control valves in industrial production is to regulate and control the flow and pressure of various materials. These materials include steam, gases, hot water and a variety of chemicals, all of which may be involved in the manufacturing process. The core task of the control valve is to keep the variable at the set point in the industrial control loop to ensure the efficiency of the production process and the stability of the product quality.

An efficient operation behind the control valve involves a complex assembly line. A standard control valve assembly line typically includes a valve body, internal precision machined components, and an actuator. The actuator is responsible for providing the necessary electric or pneumatic power to the control valve. Control valve accessories vary according to different industrial applications, common accessories include flow pressure regulators, sensors and limit switches, which help the valve to complete the adjustment task more accurately.

Why do I Need Control Valves?

In a functioning industrial plant, there are hundreds of control loops working silently in the background. These control loops are responsible for monitoring and regulating critical parameters in the plant, such as flow, pressure, temperature and material levels. Each loop is responsible for specific variables and, by coordinating with each other, keeps the entire production process stable.

However, in the process of these loops coordinating with each other, load interference can occur. When such interference occurs, the control valve, as the final link in the loop, is responsible for correcting these load disturbances, thus ensuring that the production process remains in the expected conditions. This mechanism ensures the normal operation of the plant and the production of high-quality products.

The Working Principle of the Control Valve

Although the control valve is often underestimated in the mechanical industry, it is actually an indispensable part of the control loop. The selection, installation and commissioning of control valves have a direct impact on the performance and product quality of the entire industrial system. A typical control loop consists of sensors, transmitters, and controllers.

The role of the sensor is to detect various variables in the process and transmit this information to the transmitter. The transmitter converts the data into an electrical signal that is sent to the controller. The controller compares the received data with the preset conditions and generates the necessary correction signal. This signal is then transmitted to the control valve to adjust the process variable. The sensor can be likened to the "eye", the transmitter is the "messenger", the controller is like the "brain", and the control valve is the "hand", responsible for performing the adjustment operation.

Common Errors and Precautions in Control Valve Installation

The correct installation of control valves is essential for the efficient operation of industrial equipment. Any negligence during installation can result in equipment failure or plant production disruption. Here are some common errors and considerations that require special attention when installing control valves.

Follow Instructions Manual

Always read the instructions provided by the manufacturer before installing the control valve. The manual contains installation procedures, precautions, and safety precautions. Follow the instructions in the manual to avoid possible problems during installation.

Check Control Valve

Although the manufacturer has taken precautions during production and transportation, damage can still occur during loading and unloading. Before installation, the control valve must be fully inspected to ensure that the valve has not been damaged during transportation. Check the packaging and shipping stamps to ensure that the valves are free of defects to avoid failure after installation.

Pipe Cleaning

Before installing the control valve, the end of the pipe must be thoroughly inspected. Check the end of the pipe for any damage or foreign objects, such as sheet metal, welding slag, etc. These foreign objects can damage the surface of the valve seat, causing problems during installation or even leakage. Ensuring that the pipe is clean and undamaged helps to ensure the proper installation and use of the valve.

Use of Sealants

If the valve installation requires the use of screws, the appropriate sealant must be used. Avoid using sealants on internal threads to prevent them from penetrating into the body during tightening. This penetration can cause the valve to get stuck and may cause the valve to have difficulty closing or leak. Ensure that the sealant is evenly applied to the outer thread to ensure a solid valve installation.

Correct Mounting Direction

The control valve can be installed in different positions depending on the material and nature of the pipe. The best mounting method is vertical mounting, that is, the actuator is perpendicular to the valve body. This installation avoids stem displacement due to additional weight on the top unit and internal components. Horizontal installation may cause early wear, tearing, or leakage of the valve assembly.

Conclusion

As the core regulating element in the industrial process, the performance of the control valve is directly related to the stability of production efficiency and product quality. Understanding the role of the control valve and its working principle, mastering the correct installation method and common errors, can significantly improve the operation effect and overall performance of industrial equipment.

In any industrial application, the precise operation and maintenance of control valves is essential to ensure smooth plant operation. By strictly adhering to manufacturer's installation guidelines, conducting careful pre-inspection, and taking appropriate measures to avoid common installation errors, we can maximize the role of control valves and improve factory productivity and product quality.
