Sizes: 1-4 Inch
Pressure: Class 150 LB, 300 LB, 600 LB
End Connections: Raised Face/Ring Type Joint flange
Body Materials: ASTM A352 LCC, ASTM A216 WCB, ASTM A216 WCC, ASTM A217 WC9, ASTM A217 C5, ASTM A351 CF8M, Monel
Trim Materials:
• SST 316
• SST 416
• 17-4PH
• Alloy6-Co.Cr-A
• Cobalt
• SST 316/Tungsten Carbide
Seats: PTFE/Metal
Shutoff: ANSI Class IV & V
Maximum Inlet Pressures and Temperatures: ASME 16.34.
Maximum Pressure Drops: All valves are capable of Full Rated Pressure Drops
Flow Characteristics:
• Quick opening
• Linear
• Equal percentage
Trim Options:
• Noise abatement
• Anti-cavitation
Flow Direction: Flow up through the seat ring
Valve Travel Indication: Valves are supplied with Visual Travel Indicator
Feature:
• Characteristic flow options include Equal Percentage, Linear, and Quick Open.
• Multiple Material Options: The valve is available in a variety of body and trim materials for a wide range of applications.
• Quick replacement trim for easy maintenance.
• Tight closure
