Electric Cage Type Control Valve, A217 WC6, 10 Inch, 150 LB

Key Specifications / Features

We specialize in Cage Type Control Valves, fabricated with ASTM A217 WC6 for robust performance. Our valves come in a 10-inch size, Class 150 LB pressure rating, and feature electric operation for precise control. Equipped with a durable SS 304 seat, PTFE sealing ring, and PTFE packing, they are designed for reliable operation in DN250 and PN16 applications. Ideal for demanding environments requiring efficient and consistent performance.

Hits: 84
Categories: Other Control Valves
Tags: Electric Control Valve, Cage Guided Control Valve, ASTM A217 WC6 Control Valve

Request a quote

Detail Information

Product Name: Cage Type Control Valve
Size: 10 Inch, DN250
Pressure: Class 150 LB, PN16
Body: ASTM A216 WCB, ASTM A216 WCC, ASTM A217 WC6, SS 304, SS 316
Bonnet: ASTM A216 WCB, ASTM A216 WCC, ASTM A217 WC6, SS 304, SS 316
Plug: SS 304, SS 316, SS 316L
Seat: SS 304, SS 316, SS 316L
Packing: PTFE, RPTFE, Graphite
Sealing Ring: PTFE
Stem: SS 304, SS 316, SS 316L
Operation: Electric

Technical Specifications

Nominal Diameter		25	32	40	50		65	80	100	125	150	200	250	300	350
CV	Linear	11	17.6	27.5	44		69	110	176	275	440	690	1000	1650	2160
	Equal-Percent	10	16	25	40		63	100	160	250	400	630	900	1500	2000
Rate Travel		16	25				40			60			100
Nominal Pressure (MPa)		MPa					1.6,2.5,4.0,6.4(6.3)/2.0,5,11.0,15.0
		Bar					16,25,40,64(63)20,50,110,150
		Lb					ANSI: Class 150, class 300, class 600,class 900
Inherent Flow Characteristic		Equal percentage, Linear
Inherent Adjust Rate(R)		50
Electricity Supply		220V 50HZ
Input Signal		4 to 20mA
Feedback Signal		4 to 20mA
Temperature(°C)		Normal Temperature				-20 to 200, -40 to 250, -60 to 250
		Radiator				-40 to 450, -60 to 450
		High Temperature				450 to 560(High Temperature)
		Low Temperature				-60 to -100, -100 to -200, -200 to -250
		Cutting-Off				-40 to 150(PTFE-PTFE), -60 to 200(PTFE-REINFORCED)

Dimensions

DN(mm)			25	32	40	50	65	80	100	125	150	200	250	300
L(mm)	PN16		185	205	220	254	275	300	350	410	451	600	670	735
	PN40		200	210	235	267	292	317	368	425	473	615	685	750
	PN64		210	220	251	286	311	337	394	440	508	630	700	765
H1(mm)	PN16		58	68	73	80	90	98	108	123	140	168	203	230
H1(mm)	PN40		58	68	73	80	90	98	115	135	150	188	223	255
H1(mm)	PN64		68	75	83	88	100	105	125	148	170	203	235	265
Equipped with PSL	H	Normal Temp.	614	630	635	640	712	739	761	930	940	960	1165	1185
	H	High Temp.	765	788	790	800	895	940	970	1150	1190	1220	1470	1490
	D		176							225
Equipped with 361L	H	Normal Temp.	665	725	731	755	957	980	1028	1329	1348	1423	1621	1734
	H	High Temp.	820	870	895		1125	1150	1195	1410	1586	1667	1884	2000
	D		225							310
Cryogenic Type	-196℃	H2	500		600					700
Cryogenic Type	-196℃	H	1120	1310	1320		1460	1478	1497	1850	1860	1900
